Cornier cu laturi inegale
H METAL e conectat la nevoile dumneavoastra si livreaza rapid, oriunde in tara, cornier cu laturi inegale atat la dimeniuni standard, cat si la dimensiuni atipice.
Designul acestui cornier din otel permite reducerea greutatii, facandu-l astfel ideal pentru domeniul constructiilor. Este folosit ca structura de sustinere in industria de constructii si in general in domeniul industrial pentru executia de diverse parti si piese pentru utilaje.
Dimensiuni standard de fabricatie / livrare
|
Latime |
Grosime |
Greutate |
Dimensiuni |
Suprafata |
Valori statice - AXE |
|||||||||||
|
aripi mm |
aripi t |
g |
raza r1 |
raza r2 |
A |
Cx |
Cy |
lx |
ly |
lxy |
lu |
lv |
ix |
iy |
iu |
iv |
|
a x b |
mm |
kg / ml |
mm |
mm |
cm2 |
cm |
cm |
cm4 |
cm4 |
cm4 |
cm4 |
cm4 |
cm |
cm |
cm |
cm |
|
30 x 20 |
3 |
1.12 |
4.0 |
2.0 |
1.43 |
0.99 |
0.50 |
1.25 |
0.437 |
-0.424 |
1.43 |
0.256 |
0.935 |
0.553 |
1 |
0.424 |
|
4 |
1.46 |
4.0 |
2.0 |
1.86 |
1.03 |
0.54 |
1.59 |
0.553 |
-0.53 |
1.81 |
0.33 |
0.925 |
0.546 |
0.988 |
0.421 |
|
|
40 x 20 |
4 |
1.77 |
4.0 |
2.0 |
2.26 |
1.47 |
0.48 |
3.59 |
0.596 |
-0.806 |
3.8 |
0.393 |
1.26 |
0.514 |
1.3 |
0.417 |
|
40 x 25 |
4 |
1.93 |
4.0 |
2.0 |
2.46 |
1.36 |
0.62 |
3.89 |
1.16 |
-1.21 |
4.35 |
0.701 |
1.26 |
0.688 |
1.33 |
0.534 |
|
45 x 30 |
4 |
2.25 |
4.5 |
2.3 |
2.86 |
1.48 |
0.74 |
5.75 |
2.04 |
-1.98 |
6.61 |
1.19 |
1.42 |
0.845 |
1.52 |
0.644 |
|
50 x 30 |
5 |
2.96 |
5.0 |
2.5 |
3.78 |
1.73 |
0.74 |
9.36 |
2.51 |
-2.75 |
10.3 |
1.54 |
1.57 |
0.816 |
1.65 |
0.639 |
|
60 x 30 |
5 |
3.37 |
6.0 |
3.0 |
4.29 |
2.15 |
0.68 |
15.6 |
2.6 |
-3.54 |
16.5 |
1.7 |
1.9 |
0.779 |
1.96 |
0.629 |
|
60 x 40 |
5 |
3.76 |
6.0 |
3.0 |
4.79 |
1.96 |
0.97 |
17.2 |
6.11 |
-5.91 |
19.7 |
3.54 |
1.89 |
1.13 |
2.03 |
0.86 |
|
6 |
4.46 |
6.0 |
3.0 |
5.68 |
2.00 |
1.01 |
20.1 |
7.12 |
-6.88 |
23.1 |
4.16 |
1.88 |
1.12 |
2.02 |
0.855 |
|
|
65 x 50 |
5 |
4.35 |
6.0 |
3.0 |
5.54 |
1.99 |
1.25 |
23.2 |
11.9 |
-9.72 |
28.8 |
6.32 |
2.05 |
1.47 |
2.28 |
1.07 |
|
70 x 50 |
6 |
5.41 |
7.0 |
3.5 |
6.89 |
2.23 |
1.25 |
33.4 |
14.2 |
-12.6 |
39.7 |
7.92 |
2.2 |
1.43 |
2.4 |
1.07 |
|
75 x 50 |
6 |
5.65 |
7.0 |
3.5 |
7.19 |
2.44 |
1.21 |
40.5 |
14.4 |
-14 |
46.6 |
8.36 |
2.37 |
1.42 |
2.55 |
1.08 |
|
8 |
7.39 |
7.0 |
3.5 |
9.41 |
2.52 |
1.29 |
52 |
18.4 |
-17.7 |
59.6 |
10.8 |
2.35 |
1.4 |
2.52 |
1.07 |
|
|
80 x 40 |
6 |
5.41 |
7.0 |
3.5 |
6.89 |
2.85 |
0.88 |
44.9 |
7.59 |
-10.3 |
47.6 |
4.93 |
2.55 |
1.05 |
2.63 |
0.845 |
|
8 |
7.07 |
7.0 |
3.5 |
9.01 |
2.94 |
0.96 |
57.6 |
9.61 |
-13 |
60.9 |
6.34 |
2.53 |
1.03 |
2.6 |
0.838 |
|
|
80 x 60 |
7 |
7.36 |
8.0 |
4.0 |
9.38 |
2.51 |
1.52 |
59 |
28.4 |
-23.8 |
72 |
15.4 |
2.51 |
1.74 |
2.77 |
1.28 |
|
100 x 50 |
6 |
6.84 |
8.0 |
4.0 |
8.71 |
3.51 |
1.05 |
89.9 |
15.4 |
-20.9 |
95.4 |
9.92 |
3.21 |
1.33 |
3.31 |
1.07 |
|
8 |
8.97 |
8.0 |
4.0 |
11.4 |
3.60 |
1.13 |
116 |
19.7 |
-26.7 |
123 |
12.8 |
3.19 |
1.31 |
3.28 |
1.06 |
|
|
100 x 65 |
7 |
8.77 |
10.0 |
5.0 |
11.2 |
3.23 |
1.51 |
113 |
37.6 |
-37.5 |
128 |
22 |
3.17 |
1.83 |
3.39 |
1.4 |
|
8 |
9.94 |
10.0 |
5.0 |
12.7 |
3.27 |
1.55 |
127 |
42.2 |
-42.2 |
144 |
24.8 |
3.16 |
1.83 |
3.37 |
1.4 |
|
|
9 |
11.1 |
10.0 |
5.0 |
14.1 |
3.22 |
1.59 |
141 |
46.7 |
-46.8 |
166 |
27.37 |
3.15 |
1.82 |
3.36 |
1.39 |
|
|
10 |
12.3 |
10.0 |
5.0 |
15.6 |
3.36 |
1.63 |
154 |
51 |
-50.8 |
175 |
30.2 |
3.14 |
1.81 |
3.35 |
1.39 |
|
|
12 |
14.5 |
10.0 |
5.0 |
18.5 |
3.44 |
1.71 |
179 |
59.1 |
-58.7 |
203 |
35.2 |
3.12 |
1.79 |
3.23 |
1.38 |
|
|
100 x 75 |
8 |
10.6 |
10.0 |
5.0 |
13.5 |
3.10 |
1.87 |
133 |
64.1 |
-53.8 |
162 |
34.6 |
3.14 |
2.18 |
3.47 |
1.6 |
|
10 |
13 |
10.0 |
5.0 |
16.6 |
3.19 |
1.95 |
162 |
77.6 |
-65.1 |
197 |
42.2 |
3.12 |
2.16 |
3.45 |
1.59 |
|
|
12 |
15.4 |
10.0 |
5.0 |
19.7 |
3.27 |
2.03 |
189 |
90.2 |
-75.3 |
230 |
49.5 |
3.1 |
2.14 |
3.42 |
1.59 |
|
|
120 x 80 |
8 |
12.2 |
11.0 |
5.5 |
15.5 |
3.83 |
1.87 |
226 |
80.8 |
-78.2 |
260 |
46.6 |
3.82 |
2.28 |
4.1 |
1.74 |
|
10 |
15 |
11.0 |
5.5 |
19.1 |
3.92 |
1.95 |
276 |
98.1 |
-95 |
317 |
56.8 |
3.8 |
2.26 |
4.07 |
1.72 |
|
|
12 |
17.8 |
11.0 |
5.5 |
22.7 |
4.00 |
2.03 |
323 |
114 |
-111 |
370 |
66.7 |
3.77 |
2.24 |
4.04 |
1.71 |
|
|
125 x 75 |
8 |
12.2 |
11.0 |
5.5 |
15.5 |
4.14 |
1.68 |
247 |
67.6 |
-74.2 |
274 |
40.9 |
4 |
2.09 |
4.21 |
1.63 |
|
9 |
13.6 |
11.0 |
5.5 |
17.3 |
4.18 |
1.72 |
275 |
75 |
-82.7 |
305 |
45.2 |
3.98 |
2.08 |
4.19 |
1.62 |
|
|
10 |
15 |
11.0 |
5.5 |
19.1 |
4.23 |
1.76 |
302 |
82.1 |
-90.1 |
334 |
49.9 |
3.97 |
2.07 |
4.18 |
1.61 |
|
|
12 |
17.8 |
11.0 |
5.5 |
22.7 |
4.31 |
1.84 |
354 |
95.5 |
-105 |
391 |
58.5 |
3.95 |
2.05 |
4.15 |
1.61 |
|
|
130 x 90 |
10 |
16.6 |
11.0 |
5.0 |
21.2 |
4.26 |
2.19 |
360 |
142 |
-131.6 |
422 |
79.9 |
4.12 |
2.59 |
4.46 |
1.94 |
|
12 |
19.7 |
12.0 |
6.0 |
25.1 |
4.24 |
2.26 |
420 |
165 |
-152.6 |
492 |
93.3 |
4.09 |
2.56 |
4.42 |
1.93 |
|
|
135 x 65 |
8 |
12.2 |
11.0 |
5.5 |
15.5 |
4.78 |
1.34 |
291 |
45.2 |
-64.1 |
307 |
29.4 |
4.34 |
1.71 |
4.45 |
1.38 |
|
10 |
15 |
11.0 |
5.5 |
19.1 |
4.88 |
1.42 |
356 |
54.7 |
-77.6 |
375 |
35.9 |
4.31 |
1.69 |
4.43 |
1.37 |
|
|
150 x 75 |
9 |
15.4 |
12.0 |
6.0 |
19.6 |
5.26 |
1.57 |
455 |
77.9 |
-106 |
483 |
50.2 |
4.82 |
1.99 |
4.96 |
1.6 |
|
10 |
17 |
11.0 |
5.5 |
21.6 |
5.32 |
1.61 |
501 |
85.8 |
-117 |
532 |
55.3 |
4.81 |
1.99 |
4.96 |
1.6 |
|
|
12 |
20.2 |
11.0 |
5.5 |
25.7 |
5.41 |
1.69 |
589 |
99.9 |
-136 |
624 |
64.9 |
4.79 |
1.97 |
4.93 |
1.59 |
|
|
15 |
24.8 |
11.0 |
5.5 |
31.6 |
5.53 |
1.81 |
713 |
120 |
-161 |
754 |
78.8 |
4.75 |
1.94 |
4.88 |
1.58 |
|
|
150 x 90 |
10 |
18.2 |
12.0 |
6.0 |
23.2 |
5.00 |
2.04 |
533 |
146 |
-160 |
591 |
88.3 |
4.8 |
2.51 |
5.05 |
1.95 |
|
12 |
21.6 |
12.0 |
6.0 |
27.5 |
5.08 |
2.12 |
627 |
171 |
-188 |
694 |
104 |
4.77 |
2.49 |
5.02 |
1.94 |
|
|
15 |
26.6 |
12.0 |
6.0 |
33.9 |
5.21 |
2.23 |
761 |
205 |
-225 |
841 |
126 |
4.74 |
2.46 |
4.98 |
1.93 |
|
|
150 x 100 |
10 |
19 |
12.0 |
6.0 |
24.2 |
4.81 |
2.34 |
553 |
198 |
-192 |
637 |
114 |
4.78 |
2.87 |
5.13 |
2.17 |
|
12 |
22.5 |
12.0 |
6.0 |
28.7 |
4.90 |
2.42 |
651 |
233 |
-225 |
749 |
134 |
4.76 |
2.85 |
5.11 |
2.16 |
|
|
200 x 100 |
10 |
23 |
15.0 |
7.5 |
29.2 |
6.93 |
2.01 |
1219 |
210 |
-285 |
1294 |
135 |
6.46 |
2.68 |
6.65 |
2.15 |
|
12 |
27.3 |
15.0 |
7.5 |
34.8 |
7.03 |
2.10 |
1440 |
247 |
-336 |
1528 |
159 |
6.43 |
2.67 |
6.63 |
2.14 |
|
|
15 |
33.7 |
15.0 |
7.5 |
43.0 |
7.16 |
2.22 |
1758 |
299 |
-406 |
1864 |
194 |
6.4 |
2.64 |
6.58 |
2.12 |
|
Utilizare cornier cu laturi inegale:
Cornier cu laturi inegale – reprezinta o sectiune transversala fabricata din otel carbon, sub forma unui unghi drept cu laturile de dimensiuni diferite. Acesta este cunoscut si sub numele de cornier cu aripi inegale, otel cornier inegal, profil L.
Acest cornier de otel cu laturi inegale are un nivel de toleranta stransa si poate suporta cu usurinta sarcini grele. Printre avantajele acestui produs se numara precizia dimensionala, compozitia chimica uniforma si proprietatile mecanice stabile. Poate fi utilizat si ca piesa de imbinare intre alte elemente prin sudare sau nituire.
Pentru un cornier cu laturi inegale, latimea aripilor variaza intre 20 si 100 mm pentru latura scurta si 30 - 200 mm pentru latura lunga; grosimea aripilor este cuprinsa intre 3 si 15 mm.
Aplicatii:
- diverse piese metalice
- componente structurale
- caroserii vehicule si remorci
- cladiri comerciale sau rezidentiale
- turnuri de otel
- piloni
- poduri
- vagoane
- constructie nave
- utilaje industriale
- porti si garduri
- rafturi și containere de depozitare
Caracteristici tehnice cornier cu laturi inegale:
Dimensiuni de fabricatie: conform DIN 1029 / EN 10056-1
Calitate material cornier otel: conform DIN 17100 / EN 10025
Tolerante de fabricatie: conform
EN 10056-2 Standardul stabileste tolerante de forma si dimensiuni pentru cornierele cu aripi egale si inegale, cu colturi drepte sau rotunjite.
Certificat calitate cornier cu laturi inegale: conform EN 10204 - tip 2.2 sau 3.1B
Aspect suprafata : conform EN 10163-3
